| Engine displacement | 6.8 L 415 cu in. |
|||
|---|---|---|---|---|
| Rated engine power | ECE-R120: 169 kW 230 hp |
|||
| Maximum engine power | ECE-R120: 186 kW 253 hp |
|||
| Rated PTO power (hp SAE) | 135 kW 182 hp |
|||
| Transmission type | Standard: John Deere e23™ 42 km/h 26 mph Optional: John Deere e23 Transmission 50 km/h 31 mph John Deere Infinitely Variable Transmission (IVT™) 0.050-42 km/h (0.030-26 mph) John Deere Infinitely Variable Transmission (IVT) 0.050-50 km/h (0.030- 31 mph) |
|||
| Hydraulic pump rated output | Standard: 63 cc: 162 L/min 43 gpm Optional: 85 cc: 222.3 L/min 59 gpm |
|||
| Rear hitch category (SAE designation) | Standard: Category 3/3N with Quik-Coupler Optional: Category 3/3N with hook ends |
|||
| Base machine weight | e23, TLS™, 18.4R46: 10,000 kg 22,000 lb |
| Engine type | Diesel, in-line, 6-cylinder, wet-sleeve cylinder liners with four valves in head | |||
|---|---|---|---|---|
| Engine family | MJDXL06.8309 | |||
| Rated speed | 2100 rpm | |||
| Aspiration | Dual turbochargers, variable geometry turbo with fixed geometry turbo in series | |||
| Emission level | Final Tier 4 | |||
| After treatment type | Diesel oxidation catalyst (DOC)/diesel particulate filter (DPF) | |||
| Displacement | 6.8 L 415 cu in. |
| Rated power | ECE-R120: 169 kW 230 hp |
|||
|---|---|---|---|---|
| Rated PTO power (hp SAE) | 135 kW 182 hp |
|||
| Power boost | IPM: 24 kW 30 hp |
|||
| Maximum engine power | ECE-R120: 186 kW 253 hp |
|||
| Engine peak torque | At 1600 rpm: 1077 Nm 794 lb-ft |
|||
| PTO torque rise | 40 percent |
| Type | Standard: John Deere e23™ 42 km/h 26 mph Optional: John Deere e23 transmission 50 km/h 31 mph John Deere Infinitely Variable Transmission (IVT™) 0.050-42 km/h (0.030-26 mph) John Deere Infinitely Variable Transmission (IVT) 0.050-50 km/h (0.030- 31 mph) |
|---|
| Type | Closed-center, pressure/flow compensated system with load sensing | |||
|---|---|---|---|---|
| Pump rated output | Standard: 63 cc: 162 L/min 43 gpm Optional: 85 cc: 222.3 L/min 59 gpm |
|||
| Available flow at a single rear SCV | 132 L/min 35 gpm |
|||
| Available flow at front SCVs | 126 L/min 33 gpm |
|||
| Number of rear selective control valves (SCVs) | Standard: Four SCVs Optional: Three to five ISO couplers: 12.7 mm 1/2 in. Five ISO couplers (SCV 1-5: 12.7-mm [1/2-in.] coupler) |
|||
| Number of front selective control valves (SCVs) | One with front hitch | |||
| SCV control | Electronic |
| Hitch category (SAE designation) | Standard: Category 3/3N with Quik-Coupler Optional: Category 3/3N with hook ends |
|||
|---|---|---|---|---|
| Maximum lift capacity behind lift points | Standard (Category 3): 5443 kg 12,000 lb Optional (Category 3N): 6894 kg 15,200 lb Standard (Category 3 with hook ends): 5443 kg Optional (Category 3 with hook ends): 6894 kg 15,000 lb |
|||
| Sensing type | Electrohydraulic |
| Drawbar category | Standard: Category 3 Optional: Category 3 with heavy-duty support Category 4 |
|||
|---|---|---|---|---|
| Maximum vertical load | Standard: Category 3: 1837 kg 4050 lb Optional: Category 3 with heavy-duty support: 4536 kg 10,000 lb |
| Type | Independent Standard: 44.45 mm (1.75 in.) 20-spline, 1,000 rpm Optional: 44.45 mm (1.75 in.), 20-spline, 1,000 rpm capable of 35 mm (1.375 in.) 540/1000 rpm 44.45 mm (1.75 in.) 20-spline, 1000 rpm with 35-mm (1.375-in.) 540E/1000/1000E rpm gearcase 44.45 mm (1.75 in.) 20-spline, 1000 rpm with 35-mm (1.375-in.) 540/540E/1000 rpm gearcase |
|||
|---|---|---|---|---|
| Engine rpm (at rated PTO speeds) | 540/1000 PTO rpm at 1950 engine rpm 540E/1000E PTO rpm at 1750 engine rpm |
|||
| PTO actuation | Electric switch with adjustable modulation |
| Category | Category 3N, ground engaging | |||
|---|---|---|---|---|
| Electric power | Seven-pin connector | |||
| Standard lift capacity | 5,200 kg 11,464 lb |
|||
| Front power take-off (PTO) | Available: 35 mm (1.375 in.) 21 spline, 1,000 rpm, counter-clockwise rotation (when facing PTO) Available through Parts: 44.45 mm (1.75 in.), 20 spline, 1,000 rpm, counter-clockwise rotation (when facing PTO) |
|||
| PTO speed | 1,000 PTO rpm at 1940 engine rpm |
| Type | Standard: Rack-and-pinion or flange axles Optional: Diameter: 100 x 3010 mm 3.94 x 118.5 in. Diameter: 100 x 2808 mm 3.94 x 110.5 in. Diameter: 100 x 2550 mm 3.94 x 100.4 in. Flanged axle: 335 mm 13.2 in. |
|||
|---|---|---|---|---|
| Final drive type | Inboard planetary three pinion | |||
| Rear differential lock | Full-locking electrohydraulic |
| Type | Standard: 1300 Series MFWD: tread range 1524 to 2235 mm 60 to 88 in. Optional: TLS: Tread range 1524 to 2235 mm TLS with front brakes available with 40 km/h 24.9 mph TLS with front brakes standard with 50 km/h 31 mph |
|||
|---|---|---|---|---|
| Front axle differential lock | 1300 Series MFWD: Limited slip TLS: Limited slip TLS with front brakes: Full-locking electrohydraulic (actuated at same time as rear diff lock) |
| Rear | RCI Group 47/48 | |||
|---|---|---|---|---|
| Turning radius with brakes | 380/85R34 group 42 tires at 152.4-cm (60-in.) spacing 1300: 7 m 23 ft 600/70R30 group 43 tires at 188.2-cm (74.1-in.) spacing TLS: 6.7 m 22 ft |
| Type | Standard: Hydraulic power-steering with electric pump back-up Optional: ActiveCommand Steering 2 (ACS2) w/ electronic back-up pump |
|---|
| Alternator size | Standard: 210 amp Optional: 250 amp |
|||
|---|---|---|---|---|
| Battery options | 12 V | |||
| Working lights | Standard: 18 halogen Available: 18 LED or 22 LED |
|||
| Type of bulb in headlight (Halogen, Zenon, LED) | Standard: 65-W halogen Available: LED |
|||
| Total cold cranking amps | With two 925 CCA group 31 batteries: 1850 CCA |
| Seat | Degree of seat swivel, left hand Optional: 25 degree Degree of seat swivel, right hand 40 degree Standard: Air seat Optional: ActiveSeat™ II |
|||
|---|---|---|---|---|
| Cab suspension | Optional: Adjustable cab suspension | |||
| Instructional seat | Standard | |||
| Display | Standard: G5 cm 12.8 in. |
|||
| Radio | Standard: AM/FM stereo with weatherband, remote controls, auxiliary input jack, four speakers and external antenna | |||
| Inner cab volume | 3.24 m3 114 cu ft |
|||
| Cab glass area | 6.56 m2 70.61 sq ft |
| Wheelbase | 2925 mm 115.2 in. |
|||
|---|---|---|---|---|
| Overall length | 5520 mm 217 in. |
|||
| Drawbar clearance | Group 47 rear tires: 360 mm 14.2 in. Group 48 rear tires: 415 mm 16.3 in. |
| Base machine weight | e23, TLS, 18.4R46: 10,000 kg 22,000 lb |
|||
|---|---|---|---|---|
| Maximum ballast level | SAE PTO hp: 65.8 kg 145 lb |
| Crankcase oil volume | 26 L 6.9 U.S. gal. |
|||
|---|---|---|---|---|
| Fuel tank | e23™: 463 L 122 U.S. gal. IVT: 513 L 135 U.S. gal. |
|||
| Diesel exhaust fluid (DEF) tank | 26.2 L 6.9 U.S. gal. |
|||
| Cooling system | 39.5 L 10.4 U.S. gal. |
|||
| Transmission-hydraulic system | 160 L 42.3 U.S. gal. |
| Interval for engine oil change | 500 hours | |||
|---|---|---|---|---|
| Interval for hydraulic/transmission oil change | 1,500 hours | |||
| Interval for engine coolant change | 6,000 hours |
| Loader | 700M | |||
|---|---|---|---|---|
| Lift capacity at full height | 2417 kg 5304 lb |
|||
| Maximum lift height | 4741 mm 186 in. |
| Guidance | Integrated AutoTrac™ | |||
|---|---|---|---|---|
| Telematic | JDLink™ | |||
| Remote diagnostics | ServiceADVISOR™ Remote: available with JDLink hardware and activations Remote Display Access: available with JDLink hardware and activations |
| Country of manufacture | USA |
|---|
| Date collected | 28 February 2024 |
|---|
